[SEC 01]Sheffield · CAD & design for manufacture

Drawings your shop can quote from, not query.

Example CAD is a one-person CAD bureau in Sheffield.

Drawing office capacity by the job, without carrying it on the payroll.

Start a project enquiry
Drawing office instruments on a dark slate bench, crossed by a narrow shaft of hard light: spring dividers throwing a long shadow, a steel rule catching a bright specular streak, a rolled drawing receding into shadow and an orange pencil lying at the edge of the light.
REF 01 · DRAWING OFFICE · ILLUSTRATIVE
Formats
STEP AP214 · IGES · DXF · DWG · STL
Drawing standards
BS 8888 · ISO 128
Tolerancing
ISO 1101 GD&T · ISO 2768-mK general
Commercials
Fixed price per job · NDA as standard

[SEC 02]Services

Take the drawing work off your bench

Every job is quoted fixed-price against a written scope, modelled parametrically, and delivered in the formats your machines, suppliers and quoting process already use.

A machined aluminium plate on a black granite surface plate, lit from the side so that the concentric tool-path arcs left by the cutter read as fine specular lines across the face, with an engineer's square behind it dissolving into shadow.
REF 03 · SURFACE FINISH · ILLUSTRATIVE

[SEC 03]Process

Four steps, all of them fixed at the quote

Nothing about scope, price or delivery format is left to be discovered halfway through the job.

  1. 01

    Scope

    Send sketches, a sample part, scan data or an old drawing. Back comes a written scope, a fixed price and a lead time. No day rates, no open-ended hours.

  2. 02

    Model & draw

    Work is built to your part numbering, title block and drawing standard. If none of that is written down, BS 8888 defaults apply and you are told which.

  3. 03

    Check

    Every drawing is checked back against the model before release: dimension chains close, datums reflect how the part is fixtured, tolerances are achievable on your machines.

  4. 04

    Deliver

    Native CAD, neutral formats (STEP AP214, IGES, DXF) and PDF drawings, named to your revision scheme so the file on the server matches the print at the machine.

A machined steel fixture under hard raking light: a row of milled fins throwing hard-edged shadows across a deep black background, with a single copper fastener seated in the flycut face of the block.

REF 02 · CNC MACHINING · ILLUSTRATIVE — NOT A CLIENT JOB

A second pair of eyes before the part reaches the machine, from someone who thinks in cutter diameters rather than CAD features.

[SEC 04]Recent work

Representative projects

Most client work sits under NDA, so these describe typical project shapes, scopes and deliverables rather than naming anyone.

  1. WK 01

    Weld fixture for a chassis subframe

    Fabrication · GA + 14 part drawings · STEP, PDF

  2. WK 02

    Legacy gearbox housing, reverse engineered

    Obsolete part · Measured drawing + parametric model · STEP, DXF

  3. WK 03

    Sheet-metal enclosure, DFM revision

    Electronics enclosure · Flat patterns at K-factor 0.44 · DXF

See the full portfolio

Something on the bench that needs a drawing behind it?

Send the part count, the formats you need and any fixed date.

Scope, price and lead time come back within one working day.

Start a project enquiryEmail direct
